The Imaging & optics Facility provides the option to use temporary use i) optical tools, ii) accessories and iii) high-end objectives via the Automated Rental System.
Location: building i04/BFB basement.
All items available need to be reserved in the booking system (PPMS) and the location of use should be indicated with a comment-field of the booking. Upon making a reservation, a pick up code is generated for the duration of the reservation. For overnight reservations, a second pick up / return code is generated for the following day and sent by separate email. Available items might require user rights (!), or assistance (?) for (autonomous) use. General guidelines apply
Available Objectives Rentals: user right required are required for all objectives → request training
| Item (book) |
Mag. | NA | WD (mm) | Imm. | corr | Use | Type | info |
|
Leica 506343
€€ |
20x | 0.75 | 0.66 |
IMM: water, oil, glycerol |
CORR |
Conf, CS2, TL SP8up SP8inv |
HC PL APO |
Manual I04.U1.Rent05 |
|
Leica 507706
€€€€
|
16x | 0.8 | 8.15 |
IMM: water, oil, glycerol
|
MotCORR – VISIR
|
MP, Conf., TL SP8-DIVE |
HC FLUOTAR L |
Manual I04.U1.Rent04 |
|
Leica 507703
€€€€
|
25x | 1.0 | 6.0 |
Water (only) dipping
|
ne=1,457 MotCORR – VISIR
|
MP, Conf., TL SP8-DIVE |
HC FLUOTAR L |
Manual I04.U1.Rent03 |
|
Nikon
€€€ |
10x | 0.5 | 2.5 |
MI: Oil, Water, Glycerin, Silicone Oil |
CORR – VISIR |
MP, Conf., TL Andor DF505 |
CFI P-Apo |
Manual I04.U1.Rent19 |
|
Nikon
€€€ |
20xc | 0.95 |
0.9 |
Water | Long Working Distance |
MP, Conf., TL Andor DF505 TiE2-02 |
CFI Apo LWD Lambda S |
Manual I04.U1.Rent20 |
|
Nikon €€€ |
25x | 1.05 |
0.55 |
Sil | specially suited for Live imaging |
Andor DF505 CSU-W1-01 (SoRa) CSU-W1-02 CSU-W1-03 |
CFI Plan Apo λ S |
Manual I04.U1.Rent21 |
|
Nikon €€€ |
60x | 1.20 |
0.29 (0.31-0.28) |
Water | specially suited for Live imaging |
CSU-W1-01 (SoRa) CSU-W1-02 CSU-W1-03 |
CFI Plan Apo VC |
PPMS Manual I04.U1.Rent12 |
|
Nikon
€€€ |
100xc | 1.35 |
0.31 – 0.28 |
Sil |
Selected for Super Resolution |
CSU-W1-01 (SoRa) |
CFI SR HP Plan Apo λ S |
Manual I04.U1.Rent17 |
| Item (book) |
Mag. | NA | WD (mm) | Imm. | corr | Use | Type | info |
|
Olympus
€€€€ |
10x | 0.6 |
8 |
SCALEVIEW-A2 (Water, Silicone oil, and Normal oil available) |
CORR VIS-IR |
MP, (Conf.) LaVision-up |
Request |
| Item (book) |
Mag. | NA | WD (mm) | Imm. | corr | Use | Type | info |
|
Zeiss High Res. objective set (2x) |
40x 63x |
1.2 63x |
|
Water oil |
Conf., LSM800-02, LSM880-up |
Airyscan |
I04.U1.Rent01 |
|
|
Zeiss
€€ |
20x | 1.0 |
1.8 |
Water (only) dipping |
– |
Conf., LSM800-02 LSM880-up LSM900-01 |
Plan-Apo
|
Manual Infosheet I04.U1.Rent18 |
|
Zeiss
€€ |
40x | 0.95 |
0.25 |
DRY |
Coverglass Thickness 0..13 – 0.21[mm] |
Conf., LSM800-02; SD laser cutter |
Plan-Apo
|
Manual Infosheet I04.U1.Rent22 |
|
Zeiss
€€ |
63x | 1.4 |
0.19 |
oil | Airyscan |
Conf., LSM800-02 LSM800-04 LSM800-06 LSM900-01 |
Plan-Apo |
Manual I04.U1.Rent21 |
Available Objectives Rentals: user right required are required for all objectives → request training
€€ high-value objective; €€€ very high-value objective; €€€€ extremely high-value objective
RESOURCES TO CHOOSE OBJECTIVES:
RESOURCES FOR MICROSCOPY MAINTENANCE & CLEANING OPTICS
- How to clean objectives, according to Nikon protocol
- Removing immersion from objectives, by Olympus
- Cleaning optical components, according to Leica
- Microscope cleaning and maintenance, according to Zeiss
